• H 115mm OD 76mm Marine Fuel Filter For FC-7903 Boat / Ship
  • H 115mm OD 76mm Marine Fuel Filter For FC-7903 Boat / Ship
H 115mm OD 76mm Marine Fuel Filter For FC-7903 Boat / Ship

H 115mm OD 76mm Marine Fuel Filter For FC-7903 Boat / Ship

Product Details:

Place of Origin: China
Brand Name: JV
Certification: CCS,CE
Model Number: JVL-69

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: $10-20pcs
Packaging Details: Standard export package
Delivery Time: 15-25 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000set/Month
Get Best Price Contact Now

Detail Information

Product Name: Ship Engine Fuel Filter Engine Type: Diesel / 6 Cylinders
Type: Air Filter Material: Cast Iron,Aluminum
Application: Replacement For R984C Excavator D9508 A7 Engine Spare Parts Packing: Neutral Packing
Part Name: Control Unit,oil Cooler Core Condition: New
High Light:

115mm marine fuel filter


76mm marine fuel filter


FC-7903 marine fuel filter

Product Description

Marine Engine Spare Parts Ship Engine Fuel Filter Application For FC-7903 Boat/Ship Spin-On Fuel Filter



Diesel filter is an environmentally friendly equipment that uses integrated multi-stage filtration technology to remove more than 90% of tar asphaltene and mechanical impurities in diesel




Product Detail WC-5708
# 7903
Filter Type Fuel Filter
Model Spin-On
H 1 (mm) 115
OD 1 (mm) 76
Thread Size M16X1.5-6H
Gasket ID 62.4 mm
Gasket OD 71.7 mm
Contain (pcs) 25
Volume (m3) 0.02




The installation is extremely simple, just connect it to the oil supply pipeline in series according to the reserved oil inlet and outlet ports. Pay attention to the connection in the direction shown by the arrow, and the direction of oil inlet and outlet cannot be reversed. When using and replacing the filter element for the first time, pay attention to exhaust, and the exhaust valve is on the end cover of the barrel.


How to replace the filter element:

1. Close the oil inlet ball valve and open the upper end cover. (The aluminum alloy upper end cover needs to be gently pried off from the side notch with a flat screwdriver)

2. Unscrew the plug of the sewage outlet to drain off the dirty oil.

3. Loosen the fastening nut on the upper end of the filter element, the operator wears oil-proof gloves to grip the filter element, and remove the old filter element vertically.

4. Replace with a new filter element, pad the upper seal ring (the lower end has its own seal), and tighten the nut.

5. Tighten the plugging wire of the sewage outlet, cover the upper end cover (pay attention to the gasket), and fasten the bolts.

After the above steps, we can install the clean energy diesel purifier on the car or large mechanical equipment.

Diesel filter can effectively protect the cylinder and piston, piston ring protects the fuel injector and fuel injection system, and is the protector of clean energy for large engines


H 115mm OD 76mm Marine Fuel Filter For FC-7903 Boat / Ship 0


Features of diesel filter:

It not only reduces diesel engine failures caused by diesel quality problems, but also achieves significant economic benefits in terms of fuel saving and prolonging the service life of diesel engines:

1. Extend the service life of diesel engine

2. Save fuel

3. Reduce engine maintenance costs and maintenance time.

Diesel filter is a special diesel purification equipment for diesel used in internal combustion engines. It can filter out more than 90% of the mechanical impurities, gums, asphaltenes, etc. in the diesel, which can ensure the cleanliness of the diesel to the greatest extent and increase the service life of the engine.


Unclean diesel will cause abnormal wear of the engine's fuel injection system and cylinders, reduce engine power, rapidly increase fuel consumption, and greatly reduce the service life of the generator. The use of filters can greatly improve the filtering accuracy and efficiency of engines using felt filter purifiers, and extend the life of imported high-quality products by several times, and the fuel-saving effect is obvious
