CXH1-11PL Visibility 3nm Plastic Single Deck 8W Ship Signal Lights
|Place of Origin:||China|
|Certification:||CE, CCS, ABS|
|Model Number:||CXH1-11PL, CXH2-11PL, CXH3-11PL, CXH4-11PL, CXH6-11PL|
Payment & Shipping Terms:
|Minimum Order Quantity:||1 PC|
|Packaging Details:||Standard Export Packing|
|Delivery Time:||1-7 days|
|Payment Terms:||L/C, D/A, D/P, T/T, Western Union, MoneyGram|
|Product Name:||Marine Signal Light Ship Plastic Single Deck Red Green Blue White Yellow LED Marine Signal Navigation Light||Light Source:||LED|
|Class Certificate:||IP56||Item Type:||Marine Nav. Signal Light|
|Application:||Marine Ship, Boat, Vessel, Etc||Material:||Plastic|
|Lamp Power(w):||8W||Type:||Starboard Light, Port Light, Masthead Light, Stern Light, All-round Light|
CXH1-11PL Ship Signal Lights,
3nm Ship Signal Lights,
CXH2-11PL Ship Signal Lights
Marine Signal Light Ship Plastic Single Deck Red Green Blue White Yellow LED Marine Signal Navigation Light
Specification of LED Marine Signal Navigation Light
|Type||Model||Visibility||Level arc||Light source||IP rate||Cable outside dia.||Light color||Voltage||Power|
|CXH1-11PL Single-deck starboard light||3n.m||112.5°||LED||IP56||10~12||Green||AC100-240V 50/60Hz, DC24V||8W|
|CXH2-11PL Single-deck port light||3n.m||112.5°||Red||8W|
|CXH3-11PL Single-deck masthead light||6n.m||225°||White||8W|
|CXH4-11PL Single-deck stern light||3n.m||135°||
|CXH6-11PL Single-deck all-round light||3n.m||360°||
The scope of application
Applied to the ships with the length 50m or above 50m as lamp signal liaison when night navigation.
1. The shell is made of high-strength engineering plastic PA+GF, the lampshade adopts injection of PC, lens hood adopts good quality stainless steel.
2. The signal lights have the whole seal structure, it is waterproof under the bad environment.
3. The signal lights uses exclusive LED illuminant which accords with ship rules and regulations, More energy efficient, longer working life.
4.The signal lights can work normally under the temperature -30℃－55℃.
GB/T 3028, MSC 253(8)resolution, THE INTERNATIONAL REGULATIONS FOR PREVENTINGS COLLISION AT SEA, 1972 and GRADE ENTRY NORMS FOR STEEL SHIPS.
Patent No.: ZL 201721558792.X
Marine navigation signal light series
LED, halogen, etc
Suitable ship length
From 12m to 50m
More than 50m
Red, green, blue, white,yellow
1nm, 2nm, 3nm, 6nm
|Level arc||112.5°, 135°, 225°, 360°|
Installation position Type
Single len/deck, double len/deck
Steel, plastic, brass, etc
110V, 220V, 12V, 24V
CE, CCS, ABS
1. Marine Navigation Signal Light.
2. Marine Ceiling Light, Wall Light, Portable Light, Deck Work Light, Bedside Light, Mirror Light, etc.
3. Marine Searchlight, Flood Light, etc.
4. Marine Explosion-proof Light.
5. Plug/Socket/Switch/Junction Box, etc.
Why Choose us?
For 14years, We have been providing All Marine Products with Good Quality and Price for Shipyards/Ship Owners. In this way, help you to save money and time.
1. Factory direct sale, we have our own factory to finish products.
2. Team support, our R&D department and sales will provide satisfied services 24 hours.
3. Advanced equipment, more kinds of products can be manufactured in our factory.
4. Custom services, we could make the products as your required or drawings.
5. One-stop purchase, all related products can be purchased from us.
6. Trade assurance, more safeguards could be available between us.
Q1: Why we choose you?
11 professional engineers can provide overall solution services.
13 years specialising in marine deck equipment .
18 long-term cooperation supporting factories.
24 hours a day after-sale technical support .
Q2: What kind of payments do you accept?
T/T, L/C, Western Union, D/A, D/P, MoneyGram, Paypal etc..
Q3: How about the Delivery Time?
We could finish the production within 2 days
Q4: What's the MOQ?
MOQ is 1 set.
1.Wooden Case; 2.Iron Frame; 3.According to customers' request;
By Express/ Air/ Sea/ Train.
