Marine Shipyard 50t Hydraulic Mooring Winch 650KN

Marine Shipyard 50t Hydraulic Mooring Winch 650KN

Product Details:

Place of Origin: China
Brand Name: JV
Certification: LR,CCS,BV,ABS,KR
Model Number: JVL-85

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: Standard export package
Delivery Time: 45-65 Days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000 Set/Month
Get Best Price Contact Now

Detail Information

Power Source: Hydraulic Application: Boat
Capacity: 5~650KN Material: Steel
Motor: Winch Motor Color: Customer Requirement
Usage: Marine Boat Yacht Sailboat Warranty: 12 Months
High Light:

50t Hydraulic Mooring Winch

,

Shipyard Hydraulic Mooring Winch

,

650KN Hydraulic Mooring Winch

Product Description

Marine Shipyard 50t Hydraulic Mooring Winch 650KN

Marine Hydraulic Winch Hydraulic Mooring Winch For Shipyard 50ton Winch



Main specification and parameter for hydraulic mooring winch
Specification of Hydraulic Winch
Rated Pull
(kN)
Rated Speed (m/min)
Drum Capacity
(m)
Motor Power
(kW)
10KN 10 ≥12 ø11x150 5.5
20KN 20 ≥12 ø17.5x150 22
40KN 40 ≥15 ø30x200 45
50KN 50 ≥15
ø41x250
75
75KN 75 ≥15 ø56x250 110
100KN 100 ≥12 ø64x250 132
160KN 160 ≥12 ø85x250 132



Marine Shipyard 50t Hydraulic Mooring Winch 650KN 0



Inspection method of application winch:



1. The reducer of the hydraulic winch should be maintained on a regular basis to see whether the transmission gear is engaged, whether there is movement, whether the damage of the tooth is serious, or there are cracks and other conditions.

2. The key check is to check whether the galvanized steel wire rope is coiled neatly on the drum, whether the coupling is deformed, whether the rope head is strong, if the posture of the component fails, it must be adjusted immediately.

3. When using hydraulic winches, pay attention to check whether the bolts, shaft pins, and other connecting parts fall off. It is very important to pay attention to the rolling bearing bolts. If they fall off, they should be tightened immediately.



The maintenance and maintenance of the hydraulic winch The standard operation of the hoist is important, but the maintenance and maintenance of the hoist cannot be ignored. This can not only improve the working efficiency of the hoist and prolong the service life of the hoist, but more importantly, it can reduce the damage caused during use. Unnecessary hidden dangers, it seems that the maintenance and maintenance technology of the hoist is very important. The operating specifications are as follows: 1. Do a good job of cleaning the mechanical and electrical parts of the hoist. 2. Always keep the transmission part lubricated. The bearings and gears are filled and greased with butter (calcium-based grease) respectively. The reducer is generally filled with 30# engine oil. Serious oil leakage of the reducer must be dealt with in time to ensure that the lubricating oil always maintains the specified oil level. 3. Check whether the brake is normal every shift. Adjust the gap between the brake shoe and the brake wheel in time to keep the brake in good working condition. 4. Check the wire rope frequently. When the broken wire within a lay length is greater than or equal to 10%, or there is serious corrosion, twisting, knotting, flattening and other physical deformation, the wire rope should be replaced in time. Apply wire rope oil in time according to the surface condition of the wire rope. 5. If the hoist is re-used after being idle for a long time, or after the hoist has been working for about 600 hours, the whole machine must be cleaned thoroughly. At the same time, it is necessary to determine the insulation resistance value of the hydraulic press, and check the core if necessary. Open the top cover of the transmission, check and inject new lubricating oil. Replace parts in time for easily worn parts such as brake shoes.
