• IP67 Marine Pontoon Dock Water And Power Pedestal Anti Impact
  • IP67 Marine Pontoon Dock Water And Power Pedestal Anti Impact
IP67 Marine Pontoon Dock Water And Power Pedestal Anti Impact

IP67 Marine Pontoon Dock Water And Power Pedestal Anti Impact

Product Details:

Place of Origin: Chongqing of China
Brand Name: JUVI
Model Number: JUVI

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Delivery Time: in stock
Payment Terms: Western Union, MoneyGram, D/P, D/A, L/C, T/T
Get Best Price Contact Now

Detail Information

Name: Water And Power Pedestal Application: Boat Yacht Ship Marine Marina Pontoon Port
Material 1: Stainless Steel Material 2: Aluminum Alloy
Material 3: Polyethylene Protection Class: IP56
Impact Resistance Class: IK10 Water Taps: 2pcs,1/2’ Waterpipe
High Light:

Marine Dock Water And Power Pedestal

,

IP67 Dock Water And Power Pedestal

,

Pontoon Dock Water And Power Pedestal

Product Description

IP67 Marine Pontoon Dock Water And Power Pedestal Anti Impact

 IP56 IP67 Marine Marina Pontoon Dock Water And Power Pedestal LED Light





Specification


Technical Specifications: Technical Specifications: Material : Aluminium alloy
Material : 304 stainless steel Matterial : Plastic Size : 250*250*1200mm
Size : 300*250*1200mm Size : 380*380*1000mm IP- Class: IP56
IP- Class: IP56 IP- Class: IP56 Temperature : -30°C ~ 70°C
Temperature : -30°C ~ 70°C Temperature : -30°C ~ 70°C Impact resistance class: IK10
Impact resistance class: IK10 Impact resistance class: IK10 Sockets : 4pcs, (200V~250V 2P+T) 16A/32A/63A
Sockets : 2 pcs, (200V~250V 2P+T) 16A/32A/63A Sockets : 2 pcs, (200V~250V 2P+T) 16A/32A/63A Socket IP-class: IP67
Socket IP-class: IP67 Socket IP-class: IP67 Safety : 16A/32A/63A RCBO RCD id = 30mA. Each socket is protected by an automatic circuit breaker.
Safety : 16A/32A/63A RCBO RCD id = 30mA. Each socket is protected by an automatic circuit breaker. Safety : 16A/32A/63A RCBO RCD id = 30mA. Each socket is protected by an automatic circuit breaker. Lighting : 10W 220V LED light
Lighting : 10W 220V LED light Lighting : 10W 220V LED light Water taps: 2pcs,1/2’ waterpipe
Water taps: 2pcs,1/2’ waterpipe Water taps: 2pcs,1/2’ waterpipe Intelligent lighting device : Intelligent optical receiving inductor
Intelligent lighting device : Intelligent optical receiving inductor Intelligent lighting device : Intelligent optical receiving inductor Electricity meter: Advanced electronic watt-hour meter
Electricity meter: Advanced electronic watt-hour meter Electricity meter: Advanced electronic watt-hour meter Water meter: Liquid seal, high sensitive meter
Water meter: Liquid seal, high sensitive meter Water meter: Liquid seal, high sensitive meter
  Intelligent system: for intelligent card pay electricity supply device





The initiative to control water and electricity by intelligent plug-in card: real-time billing and metering, time, stored value, recharge, remote control, etc.
Perfect solution to outdoor installation and using socket without fixed wall.





Pontoon (boat or floating box instead of bridge, bridge floating in the water)



Pontoon, refers to the bridge of the bridge, floating on the water, or floating box. The army adopts the military pontoon of the formulation equipment, which is called the boat bridge. The historical record of the pontoon is early in China. "Book of Songs, Da Ya Daming" records: "Welcome to the Yuxi, Zhou Zhan is Liang", record Zhou Wen Wang Jichang in the Weihe frame pontoon in 1184 BC. In foreign countries, the Persi Dynasty Russian Emperor built a pontoon in Mesopia in May 537 BC.





Fender



The fender, also known as the ship's handguard, is an elastic buffer device used on the pier or the edge of the ship, which is made of wood or rubber.



It is mainly used to slow down the impact force between the ship and the dock or the ship in the process of docking or mooring, and reduce or eliminate the damage to the ship and the dock.





Feature:

1.High impact resistance

2.UV and salt water resistance

3.Zero corrosion

4.UV proof



Technical Specifications:

Material : 304 stainless steel

Size : 300*250*1200mm

IP- Class: IP56

Temperature : -30°C ~ 70°C

Impact resistance class: IK10

Sockets : 2 pcs, (200V~250V 2P+T) 16A/32A/63A

Socket IP-class: IP67

Safety : 16A/32A/63A RCBO RCD id = 30mA. Each socket is protected by an automatic circuit breaker.

Lighting : 10W 220V LED light

Water taps: 2pcs,1/2’ waterpipe

Intelligent lighting device : Intelligent optical receiving inductor

Electricity meter: Advanced electronic watt-hour meter

Water meter: Liquid seal, high sensitive meter





Material : Aluminium alloy

Size : 250*250*1200mm

IP- Class: IP56

Temperature : -30°C ~ 70°C

Impact resistance class: IK10

Sockets : 4pcs, (200V~250V 2P+T) 16A/32A/63A

Socket IP-class: IP67

Safety : 16A/32A/63A RCBO RCD id = 30mA. Each socket is protected by an automatic circuit breaker.

Lighting : 10W 220V LED light

Water taps: 2pcs,1/2’ waterpipe

Intelligent lighting device : Intelligent optical receiving inductor

Electricity meter: Advanced electronic watt-hour meter

Water meter: Liquid seal, high sensitive meter





Technical Specifications:

Matterial : Plastic

Size : 380*380*1000mm

IP- Class: IP56

Temperature : -30°C ~ 70°C

Impact resistance class: IK10

Sockets : 2 pcs, (200V~250V 2P+T) 16A/32A/63A

Socket IP-class: IP67

Safety : 16A/32A/63A RCBO RCD id = 30mA. Each socket is protected by an automatic circuit breaker.

Lighting : 10W 220V LED light

Water taps: 2pcs,1/2’ waterpipe

Intelligent lighting device : Intelligent optical receiving inductor

Electricity meter: Advanced electronic watt-hour meter

Water meter: Liquid seal, high sensitive meter

Intelligent system: for intelligent card pay electricity supply device

IP67 Marine Pontoon Dock Water And Power Pedestal Anti Impact 0IP67 Marine Pontoon Dock Water And Power Pedestal Anti Impact 1IP67 Marine Pontoon Dock Water And Power Pedestal Anti Impact 2
