160KW Marine Diesel Generator Set
Product Details:
| Place of Origin: | China |
| Brand Name: | JUVI |
| Certification: | CE, ISO, SONCAP |
| Model Number: | 160KW/200KVA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PC |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Nude packing |
| Delivery Time: | 25 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000+PCS+Month |
|
Detail Information |
|||
| Product Name: | 160KW/200KVA Genset Cummins Engine AC 3 Phase Silent Open Marine Diesel Generator Set | Engine Brand: | YUCHAI, WEIFANG/WEICHAI, CUMMINS, LIJIA&RICHARD, SHANGCHAI&YANGDONG,LOVAL, DEUTZ D&BF, DEUTZ F, PERKINS, YANMAR &KUBOTO |
|---|---|---|---|
| Certificate: | CE, ISO, SONCAP | Color: | Green, Yellow, Red, Blue, Optional |
| Warranty: | 1 Year | Excitation: | Brushless |
| Type: | Open Or Slient | Package: | 3100*1200*1900mm（L×W×H） |
| High Light: | 160KW Marine Diesel Generator Set,200KVA Marine Diesel Generator Set,200KVA marine generator set |
||
Product Description
160KW/200KVA Genset Cummins Engine AC 3 Phase Silent Open Marine Diesel Generator Set
Specification of 50KVA Diesel Generator Sets
| 160KW diesel generator set reference parameters | |
| Diesel engine technical parameters | |
| Model:GF2-160 | Frequency settling time(S):≤3 |
| Power:160kw/200KVA | Transient Frequency Regulation(%):＋10～－7 |
| Rated power factor:COSΦ=1.0 lagging | Frequency fluctuation rate(%):≤±0.5 |
| Rated voltage:380V | Steady - state frequency adjustment rate(%):≤±1 |
| Rated current:524.8A | Voltage settling time(s):≤1 |
| Rated Freq:60HZ | Transient Voltage Regulation(%):＋20～－15 |
| Rated Speed:1800RPM | Voltage fluctuation rate(%):≤±0.5 |
| Start control mode:Electric start | Steady - state voltage regulation rate(%):≤±1 |
| Package size:3100*1200*1900mm(L×W×H) | Net weight:1500KG |
| Diesel engine technical parameters: | |
| Origin/brand:YUCHAI | Start mode:Electric start |
| Engine Model:YC6A245L-D20 | Oil supply:Direct injection |
| Engin power(KW):165/181KW | Speed regulation:Mech. regulation |
| Bore*Stroke:112/132mm | Intake mode:Natural Aspiration |
| Cylinder Number:6/L | Cooling method:Closed water circulation cooling |
| Overloadiing:100% | Speed:1800Rpm |
| Fuel type:(Standard) 0 # light diesel oil (room temperature) | |
| Alternator technical parameters | |
| Origin/brand:JUVI | Rated power factor:COSΦ=0.8 lagging |
| Model:XYT-160 | Speed:1800rpm |
| Power:160kw/200KVA | Adjustment mode:AVR |
| Rated voltage:380V | Connection method:Single Phase Two Line |
| Rated current:303.8A | Protection class:IP22 |
| Rated Frq:60HZ | Insulation class: H |
| Rated Speed:1800RPM | |
| Genset standard configuration as follows: | |
| Direct injection internal combustion engine(diesel oil)； | |
| AC synchronous brushless alternator(single bearing)； | |
| Power output air switch, standard silent Box ；Unit common steel base fuel tank and Smartgen Controller. | |
| Dry air filters, fuel filters, lubricating oil filters, starter motors, and self-charging generators； | |
| Start the battery and battery start connection cable； | |
| Random data: Diesel engine and generator original technical documentation, generator sets and other instructions. | |
| Type | Open/Silent |
| Engine Brand |
YUCHAI, WEIFANG/WEICHAI, CUMMINS, LIJIA&RICHARD, SHANGCHAI&YANGDONG,LOVAL, DEUTZ D&BF, DEUTZ F, PERKINS, YANMAR &KUBOTO |
| Class certificate | CE, ISO, SONCAP |
| Color |
Green, Yellow, Red, Blue, Optional |
| Power | 5KW/KVA - 4000KW/KVA |
