30KW Marine Diesel Generator Set

30KW Marine Diesel Generator Set

Product Details:

Place of Origin: China
Brand Name: JUVI
Certification: CE, ISO, SONCAP
Model Number: 400KW/500KVA

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: Negotiable
Packaging Details: Nude packing
Delivery Time: 25 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000+PCS+Month
Get Best Price Contact Now

Detail Information

Product Name: Sound Proof Silent Diesel Generator 4KW 5KW 20KW 30KW Marine Diesel Generator Set Engine Brand: YUCHAI
Certificate: CE, ISO, SONCAP Color: Green, Yellow, Red, Blue, Optional
Warranty: 1 Year Size: 4500*1800*2200mm(L*W*H )
Excitation: Brushless Type: Open Or Slient
High Light:

30KW Marine Diesel Generator Set

,

20KW Marine Diesel Generator Set

,

5KW Marine Diesel Generator Set

Product Description

30KW Marine Diesel Generator Set

Sound Proof Silent Diesel Generator 4KW 5KW 20KW 30KW Marine Diesel Generator Set





Specification of Diesel Generator Sets



400KW Yuchai diesel generator reference parameters
Generator set technical parameters:
Model:JVGF2-400 Frequency settling time(S):≤3
Power:400KW/500KVA Transient Frequency Regulation(%):+10~-7
Rated power factor:COSΦ=0.8agging Frequency fluctuation rate(%):≤±0.5
Rated voltage:380V Steady - state frequency adjustment rate(%):≤±1
Rated current:759A Voltage settling time(s):≤1
Rated Freq:60HZ Transient Voltage Regulation(%):+20~-15
Rated Speed:1800RPM Voltage fluctuation rate(%):≤±0.5
Start control mode:Electric start Steady - state voltage regulation rate(%):≤±1
Dimensions:4500*1800*2200(L*W*H MM) Net weight:5100KG
Diesel engine technical parameters:
Origin/brand:Guangxi/Yuchai Start mode:Electric start
Engine Model:YC6K600-D30 Oil supply:Direct injection
Engin power(KW):401/441KW Speed regulation:Mech. regulation
Bore*Stroke:145*165 mm Intake mode:Turbocharged&Intercooled
Cylinder Number:6/L Cooling method:Closed water circulation cooling
Fuel consumption:≤195g/kw.h Speed:1800Rpm
Overloadiing:100% Fuel type:(Standard) 0 # light diesel oil (room temperature)
Alternator technical parameters:
Origin/brand:JUVI Rated power factor:COSΦ=0.8 lagging
Model:XYT-400 Speed:1800rpm
Rated Current:759A Adjustment mode:AVR
Rated Voltage:380V Connection method:Three Phase Four Line
Rated Frq:60HZ Protection class:IP22
Rated Speed:1800RPM Insulation class: H
Genset standard configuration as follows
Direct injection internal combustion engine(diesel oil);
AC synchronous brushless alternator(single bearing);
Dry air filters, fuel filters, lubricating oil filters, starter motors, and self-charging generators;
battery and battery start connection cable
Random data: Diesel engine and generator original technical documentation, generator sets and other instructions.



Type Open/Silent
Engine Brand

YUCHAI, WEIFANG/WEICHAI, CUMMINS, LIJIA&RICHARD, SHANGCHAI&YANGDONG,LOVAL, DEUTZ D&BF, DEUTZ F, PERKINS,

YANMAR &KUBOTO

Class certificate CE, ISO, SONCAP
Color

Green, Yellow, Red, Blue, Optional

Power  5KW/KVA - 4000KW/KVA



Why Choose us?



1. Factory direct sale, we have our own factory to finish products.

2. Team support, our R&D department and sales will provide satisfied services 24 hours.

3. Advanced equipment, more kinds of products can be manufactured in our factory.

4. Custom services, we could make the products as your required or drawings.

5. One-stop purchase, all related products can be purchased from us.

6. Trade assurance, more safeguards could be available between us.
