Fully Automatic Water Yield 30m3/D AC380V RO System Seawater Treatment Equipment

Fully Automatic Water Yield 30m3/D AC380V RO System Seawater Treatment Equipment

Product Details:

Place of Origin: China
Brand Name: JUVI
Certification: BV, CCS, etc
Model Number: JV-SW-120

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: Negotiable
Packaging Details: Nude packing/ Pallet
Delivery Time: 25 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000+PCS+Month
Get Best Price Contact Now

Detail Information

Product Name: Seawater Treatment Equipment Fully Automatic Seawater Treatment Plant By RO System RO Type: 2 Stage RO
High Pressure Pump: Grundfos(Optional) Operating: Automation And Manual
RO Membrane: USA Dow(Optional) Recovery Rate: The First Stage:40%, The Second Stage:88%
Usage: Drinking Water, Industrial Process Water Treatment Voltage: AC 380V/50 Hz(If Special, Can Be Customized)
High Light:

30m3/D Seawater Treatment Equipment

,

AC380V Seawater Treatment Equipment

,

50m3/D Seawater Treatment Equipment

Product Description

Fully Automatic Water Yield 30m3/D AC380V RO System Seawater Treatment Equipment

Seawater Treatment Equipment Fully Automatic Seawater Treatment Plant by RO System





Specification of Sea Water Desalination Plant



Model

Water

Yield

Desalination

Rate

Output Water

Saltness

Recovery

Rate

Voltage

Weight

m3/d

%

mg/L

%

V

KG

JV-SW-30

30

≥99.5

<700

28

380V 50HZ
Three Phase

460

JV-SW-50

50

35

530

JV-SW-60

60

40

600

JV-SW-720

72

40

6000

JV-SW-120

120

45

7000

JV-SW-240

240

45

8000

JV-SW-360

360

45

5000

JV-SW-720

720

45

17000

JV-SW-1000

1000

45

18000

JV-SW-2000

2000

45

36000

JV-SW-5000

5000

45

80000

JV-SW-10000

10000

45

160000



Configuration


1. RO Membrane: USA DOW/ HYDRANAUTICS/ GE

2. Pressure Vessel: First Line, FRP Material
3. Raw Water Booster Pump: Grundfos/ CNP
4. High Pressure Pump: Grundfos/ CNP
5. Device Framework: Indus try-standard thick- walled stainless steel tube, and pipe outer surface is polished
6. Pipeline: The high-pressure side pipe line adopts dual-phase steel or stainless steel pipelines and high-pressure hoses. Low-pressure side pipe uses UPVC pipe
7. Electric Element: OMRONS PLC, ABB Frequency inverter, Schneider Electric element



Performance and Features


1. Reverse osmosis seawater desalination technology is mature and advanced, the desalination rate is up to 99.5%.
2. Energy saving design, low energy consumption and low cost of water production.
3. Rigorous process design ensures long :system life and low maintenance costs.
4. Easy to operated and maintained, cleaned and repaired without disassemble, easy to managed.
5. Equipment Combination Type: Frame Type, Container Type.
6. Customized according to customers' needs.



Products series



Small Seawater Desalination series
Medium and Large Seawater Desalination series
Brackish Water Desalination series
Pure Water Desalination series
EDI series
Reclaimed-Water Recycling series
Integrated Sewage Treatment Equipment
Installation Kit series



Product Introduction



Medium and large-scale seawater desalination equipment is suitable for cargo ships, oil tankers, offshore drilling platforms, islands, stations and coastal water-scarce cities. The RO system adopts the most advanced RO system design software and the highest quality membrane originals, combined with efficient and unique capacity recovery technology according to the water production of the equipment, which can effectively remove inorganic salts, heavy metal ions, organic bacteria and bacteria in seawater. Removal of harmful components such as germs. Desalinate seawater into drinking water that meets national standards (GB5749-2006). The entire system is equipped with advanced flow and pressure control instruments and safety pressure relief devices, and is equipped with an advanced detection and monitoring system to ensure that the system runs smoothly and produces high-quality water (when the water quality exceeds the warning salinity value, the system automatically opens for drainage Valve, lead the product water into the waste water channel) and provide accurate values for the operation of the system.



Company Introduction



Chongqing JUVI Marine Machinery Co., LTD is an integrated marine technology company that presently specializes in product design, production, and sales.Juvi company is administered by the marine equipment production systems. Every factory that our partner with has passed the CCS, ABS, DNV, LR, NK, RINA, ISO9002, TS16949, UL and other related systems authentication.
More than 14 years of accumulated experience, high-quality products, coupled with our philosophy of absolute integrity in all business dealings have earned us unanimous praise from old and new clients alike, as well as a distinctive reputation in the industry.



Our products have sold to regions as far away as Europe, North America and Asia, among others. We regularly introduce the most advanced foreign products and technologies into the domestic market and routinely share the latest in scientific and technological advancements with related domestic industries, thus providing a platform of speed and convenience From our beginnings as an international trade business model to an integrated technology solutions business model, JUVI Company has grown and transformed
itself to better serve the needs of our customers.
