• 8 Layer Dock Port Salvage 12M Ship Launching Airbags
  • 8 Layer Dock Port Salvage 12M Ship Launching Airbags
8 Layer Dock Port Salvage 12M Ship Launching Airbags

8 Layer Dock Port Salvage 12M Ship Launching Airbags

Product Details:

Place of Origin: Chongqing of China
Brand Name: JUVI
Model Number: 12meter

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Delivery Time: in stock
Payment Terms: Western Union, MoneyGram, D/P, D/A, L/C, T/T
Get Best Price Contact Now

Detail Information

Name: Ship Airbag Application: Ship Marine Boat Vessel Yacht
Certificate:: CCS / SGS / BV / ISO9001 Etc. Working Pressure:: 0.05MPa To 0.15Pa
Type 1: 6-8 Layer Lifespan:: 8~10 Years
MOQ: 1 Pc
High Light:

12M Ship Launching Airbags

,

Salvage Ship Launching Airbags

,

Dock Port Ship Launching Airbags

Product Description

8 Layer Dock Port Salvage 12M Ship Launching Airbags

Ship Marine Boat Dock Port Salvage Launching Rubber Airbag 12M



Specification



Airbag Layer and Pressure:
  D=0.8m D=1.0m D=1.2m D=1.5m D=1.8m D=2.0m
3 layers 0.13MPA 0.10MPA 0.09MPA 0.07MPA 0.06MPA 0.05MPA
4 layers 0.17MPA 0.13MPA 0.11MPA 0.09MPA 0.08MPA 0.07MPA
5 layers 0.21MPA 0.17MPA 0.14MPA 0.11MPA 0.09MPA 0.08MPA
6 layers 0.25MPA 0.20MPA 0.17MPA 0.13MPA 0.11MPA 0.10MPA
7 layers 0.29MPA 0.23MPA 0.20MPA 0.15MPA 0.13MPA 0.12MPA
8 layers 0.33MPA 0.26MPA 0.23MPA 0.17MPA 0.15MPA 0.14MPA



8 Layer Dock Port Salvage 12M Ship Launching Airbags 0

Marine airbag



The airbag for heavy lifting and launching and launching of ships is an innovative product with my country's independent intellectual property rights. It is widely used in ship launching and launching, caisson lifting and transporting, handling of other heavy objects, and floating aid in underwater installation projects. field.



The application of marine airbags is less restricted by space and does not require large-scale machinery and equipment, so it can shorten the engineering cycle and save a lot of money. After more than 20 years of development and practice, it has been proved that this product has the characteristics of safety, efficiency, green environmental protection, mobility and flexibility.





Airbag storage



When the airbag is not used for a long time, it should be washed and dried, filled with talcum powder on the outside, and placed in a dry, cool and ventilated place indoors. The airbag should be stretched out and placed flat, not stacked, and no heavy objects should be stacked on the airbag.

The place where the air bag is stored should be far away from heat sources.



The airbag should not be in contact with acids, alkalis, grease and organic solvents.



Airbag packaging and transportation



According to the People’s Republic of China Shipping Industry Standard CB/T 3795-1996, the packaging, transportation and storage of marine airbags should follow the following standards:

  1, packaging

   After folding, it is bundled and packed with a plastic woven bag.

  2, transportation

   When the airbag is transported in a short distance, it should be hoisted, lifted, and rolled in an inflated state. Towing on the ground is strictly prohibited.

   Airbags should be folded and fixed on a pallet during long-distance transportation, with cushions underneath and wrapping with stretch film on the outside.



Fender



The fender, also known as the ship's handguard, is an elastic buffer device used on the pier or the edge of the ship, which is made of wood or rubber.



It is mainly used to slow down the impact force between the ship and the dock or the ship in the process of docking or mooring, and reduce or eliminate the damage to the ship and the dock.
