Hydraulic 15kN 7.5kW Dia 19mm LRS Certification Marine Anchor Windlass

Hydraulic 15kN 7.5kW Dia 19mm LRS Certification Marine Anchor Windlass

Product Details:

Place of Origin: China
Brand Name: JV
Certification: LR,BV,CCS,KR
Model Number: JVL-9

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: $2000-20000/set
Packaging Details: Standard export pakcage
Delivery Time: 30-50 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000set/Month
Get Best Price Contact Now

Detail Information

Part: Windlass Application: Maritime
Material: Steel Usage: Install In Boat
Paint: As Customers' Need Type: Hydraulic Anchor Windlass
Drive: Electric Or Hydraulic Control: Local Control
High Light:

19mm Marine Anchor Windlass

,

7.5kW Marine Anchor Windlass

,

15kN hydraulic anchor windlass

Product Description

Hydraulic 15kN 7.5kW Dia 19mm LRS Certification Marine Anchor Windlass

Marine Anchor Windlass Dia 19mm Anchor Windlass 15kN 7.5kW Hydraulic Anchor Windlass





Windlass: Chain Dia Φ19-132mm

Mooring Winch: 5-2000kN
Chian Wheel: Carbon steel casting
Certification: LRS, ABS, BV, KR, CCS, etc.
Gypsy Size: U2 / U3
Working speed: 10m/min

Chongqing Juvi marine machinery company is an integrated marine technology company that presently specializes in product design, production, and sales. Juvi company is administered by the marine equipment production systems. Every factory that our partnership with has passed the CCS, ABS, DNV, LR, NK, RINA, ISO9002, TS16949, UL, and other related systems authentication.
More than 10 years of accumulated experience, high-quality products, coupled with our philosophy of absolute integrity in all business dealings have earned us unanimous praise from old and new clients alike, as well as a distinctive reputation in the industry.
Our products have sold to regions as far away as Europe, North America, and Asia, among others. We regularly introduce the most advanced foreign products and technologies into the domestic market and routinely share the latest in scientific and technological advancements with related domestic industries, thus providing a platform of speed and convenience From our beginnings as an international trade business model to an integrated technology solutions business model, Juvi Company has grown and transformed itself to better serve the needs of our customers.

Q1: Why we choose you?

11 professional engineers can provide overall solution services.
13 years specializing in marine deck equipment.
18 long-term cooperation supporting factories.
24 hours a day after-sale technical support.

Q2: What kind of payments do you accept?

T/T, L/C, Western Union, D/A, D/P, MoneyGram, Paypal, etc.

Q3: How about the Delivery Time?

We could finish the production within 30 days

Q4: What's the MOQ?

MOQ is 1 set.



Main specification and parameter for hydraulic windlass
Specification of Hydraulic Windlass
Chain Dia
(mm)
Working Load
(kN)
Weigh Anchor
Speed
(m/min)
Towing Force
(kN)
Towing Speed
(m/min)
Motor Power
(kW)
19
19
15.3
≥9
15
≥12
7.5
28
28
33.3
≥9
25
≥12
15
38
38
61.4
≥9
50
≥12
30
56
56
133.3
≥9
80
≥15
40
76
76
245.5
≥9
147
≥15
60
92
92
402.2
≥9
200
≥15
115
105
105
523.7
≥9
250
≥15
145
132
132
827.64
≥9
300
≥15
250
