• 40KW Cummins Engine 50KVA Brushless Silent Marine Diesel Generator Set
  • 40KW Cummins Engine 50KVA Brushless Silent Marine Diesel Generator Set
40KW Cummins Engine 50KVA Brushless Silent Marine Diesel Generator Set

40KW Cummins Engine 50KVA Brushless Silent Marine Diesel Generator Set

Product Details:

Place of Origin: China
Brand Name: JUVI
Certification: CE, ISO, SONCAP
Model Number: 50KVA

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: Negotiable
Packaging Details: Nude packing
Delivery Time: 25 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000+PCS+Month
Get Best Price Contact Now

Detail Information

Product Name: 50KVA Genset Cummins Engine Brushless Silent Marine Diesel Generator Set Engine Brand: YUCHAI, WEIFANG/WEICHAI, CUMMINS, LIJIA&RICHARD, SHANGCHAI&YANGDONG,LOVAL, DEUTZ D&BF, DEUTZ F, PERKINS, YANMAR &KUBOTO
Certificate: CE, ISO, SONCAP Color: Green, Yellow, Red, Blue, Optional
Warranty: 1 Year Excitation: Brushless
Type: Open Or Slient Package: Nude Packing
High Light:

50KVA Marine Diesel Generator Set

,

40KW Marine Diesel Generator Set

,

50KVA cummins marine diesel generator

Product Description

40KW Cummins Engine 50KVA Brushless Silent Marine Diesel Generator Set

50KVA Genset Cummins Engine Brushless Silent Marine Diesel Generator Set



Specification of 50KVA Diesel Generator Sets



Cummins silent diesel generator reference parameters
Generator set technical parameters:
Model:GF-40 Frequency settling time(S):≤3
Power:40KW/50KVA Transient Frequency Regulation(%):+10~-7
Rated power factor:COSΦ=0.8 lagging Frequency fluctuation rate(%):≤±0.5
Rated voltage:380V Steady - state frequency adjustment rate(%):≤±1
Rated current:75.9A Voltage settling time(s):≤1
Rated Freq:50HZ Transient Voltage Regulation(%):+20~-15
Rated Speed:1500RPM Voltage fluctuation rate(%):≤±0.5
Start control mode:Electric start Steady - state voltage regulation rate(%):≤±1
Dimensions:2300*1000*1300(L×W×Hmm) Net weight:1000KG
Diesel engine technical parameters:
Origin/brand:Cummins Start mode:Electric start
Engine Model:4BTA3.9-G2 Oil supply:Direct injection
Engin power(KW):50/60KW Speed regulation:Elec. regulation
Bore*Stroke:102*120MM Intake mode:Turbo
Cylinder Number:4/L Cooling method:Closed water circulation cooling
Fuel consumption:≤220g/kw.h Speed:1500Rpm
Overloadiing:100% Fuel type:(Standard) 0 # light diesel oil (room temperature)
Alternator technical parameters:
Origin/brand:Stamford Rated power factor:COSΦ=0.8 lagging
Model:UCI224D Speed:1500rpm
Rated current:75.9A Adjustment mode:AVR
Rated Voltage:380V Connection method:Three Phase Four Line
Rated Frq:50HZ Protection class:IP21
Rated Speed:1500RPM Insulation class: H
Genset standard configuration as follows
Direct injection internal combustion engine(diesel oil);
AC synchronous brushless alternator(single bearing);
Power output air switch, standard silent Box ;
Unit common steel base fuel tank;
Start the battery and battery start connection cable;
Dry air filters, fuel filters, lubricating oil filters, starter motors, and self-charging generators;
Random data: Diesel engine and generator original technical documentation, generator sets and other instructions.





Type Open/Silent
Engine Brand

YUCHAI, WEIFANG/WEICHAI, CUMMINS, LIJIA&RICHARD, SHANGCHAI&YANGDONG,LOVAL, DEUTZ D&BF, DEUTZ F, PERKINS,

YANMAR &KUBOTO

Class certificate CE, ISO, SONCAP
Color

Green, Yellow, Red, Blue, Optional

Power  5KW/KVA - 4000KW/KVA
