15W Marine Signal Lights

15W Marine Signal Lights

Product Details:

Place of Origin: Chongqing of China
Brand Name: JUVI
Model Number: CXH-5

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Delivery Time: in stock
Payment Terms: Western Union, MoneyGram, D/P, D/A, L/C, T/T
Get Best Price Contact Now

Detail Information

Name: Ship Boat Head Light Power: 15W/ 30/ 60W
Material: Aluminum/ Plastic Lamp Holder: E27/ B15d
Protection Class: IP56 Level Arc: 360 Degree
Visibility: 2n.m/ 3n.m Weight: 0.86kg
High Light:

CXH-5 Marine Signal Lights

,

15W Marine Signal Lights

,

CXH-5 Navigation Signal Lamp

Product Description

15W Marine Signal Lights

Ship Boat Head Navigation Signal Lamp CXH-5 360 Degree 2N.M 3N.M




Specification


    Visibility Level arc Color Weight Power Cable outside Diameter (mm) Material Lamp Holder Protection class Rated voltager
CXH-5 head light CXH5-1 3n.m 360. Transparent/ Red/ Green/ Yellow/
Blue/ Purple
0.86kg 60W 12 Aluminum E27 IP56 24V 110V 220V
CXH5-1A 3n.m Transparent/ Red/ Green/ Yellow/
Blue/ Purple
0.73kg 60W 12 Plastic E27 24V 110V 220V
CXH5-2 2n.m Transparent/ Red/ Green/ Blue 0.47kg 30W 15 Aluminum B15d 24V
CXH5-2A 2n.m Transparent/ Red/ Green/ Blue 0.39kg 30W 15 Plastic B15d 24V
CXH5-3 2n.m Transparent/ Red/ Green 0.3kg 15W   Plastic B15d 12V 24V


CXH-5 head light

The scope of application:

Applied to the ships as lamp signal when night navigation.

Products characteristic:

1. Screw-type connecting flange, it is convenient to install and replace the bulb.
2. The lampshade adopts good quality pyrex glass, and it has good function of pervious to light.

Adopt standard:

1. Conform toand
2. Conform to the standard of marine electric signal light's technical condition GB/T 3028-1995.

Production authentication:

Approval by CCS(China Classification Society), certificate number 00515Q20619ROM.

15W Marine Signal Lights 015W Marine Signal Lights 115W Marine Signal Lights 2





Masthead light:



The signal lights placed above the mast of the ship or above the centerline of the fore and aft, display uninterrupted lights in a horizontal arc of 225 degrees, and the device should display the lights from the front of the ship to within 22.5 degrees behind each side.



Starboard light and Port light:



The red light on the port side and the green light on the starboard side, which are placed on the left and right sides of the highest deck of the ship, each display uninterrupted lights in a horizontal arc of 112.5 degrees. Displayed within 22.5 degrees behind the abbe. The sidelight shield facing the lamp surface shall be painted with matt black paint. The height of the shutter is at least equal to the height of the lamp. For barges with a length of 80 meters or more, red and green side lights shall be installed at the bow and stern.



Stern ight:



A white light located in the middle of the stern. Display uninterrupted lights in a horizontal arc of 135 degrees, and the device should make the lights display within 67.5 degrees of each side from directly behind the ship. The height of the masthead light should be as horizontal as possible, but not higher than the sidelight.



Head light:



It refers to a white light placed on the bow of the pushed barge, which displays uninterrupted light in a 180-degree horizontal arc. The device must make the light display from the front of the ship to within 90 degrees of each side, but not high On the side light.



All-round light:



The lights of uninterrupted lights are displayed in a 360-degree horizontal arc.
