Product Details:

Place of Origin: China
Brand Name: JV
Certification: CE,CCS
Model Number: JVL-23

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: $9-15/pcs
Packaging Details: Standard export package
Delivery Time: 15-25 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs/Month
Get Best Price Contact Now

Detail Information

Product Name: Ship Work Light Power: 15W,60W,100W
Material: Synthetic Resin,Aluminium Color: Transparent,Red,Green
Protection Class: IP56 Weight: 1.2Kg
Lamp Holder: FB22,FB26 Installation: Celling-type
High Light:

DS7-2M Marine Work Lights

,

DS7-3M Marine Work Lights

,

60W 220V Marine Work Lights

Product Description

DS7-2M DS7-3M Weight 1.2Kg Power 60W 220V Marine Work Lights

Marine Work Light DS7-3M Ship Dry Cabin Work Light With 220V Red Green Boat Light​





The scope of application:


This series lights fit for the ships with water dripping, water spattering, water coagulating and weather place, such as oven cabin room, dry cabin, tunnel, pipeline and weather deck.



Products characteristic:


The lampshade is a bolt blocking device, and convenient to connect, ceiling-type installation.
Production authentication
1. Approval by CCS(China Classification Society), certificate number 00515Q20619R0M.
2. Passed the authentication of CE.
3. Adopt the Japanese standard JISF8414- 2003.
4. Conform to.



Code
Type
Protection class
Voltage
Power
Certificate
Lamp
Weight
792057
DS7-2M
IP56
220V
60W
CCS/CE
FE26
1.2kg



DS7-2M DS7-3M Weight 1.2Kg Power 60W 220V Marine Work Lights 0



DS7-2M DS7-3M Weight 1.2Kg Power 60W 220V Marine Work Lights 1



Types:



The design and manufacture of ship lights must comply with the relevant provisions of ship regulations and international conventions, and can be installed and used only after the ship inspection department has passed the inspection and issued a certificate.



In accordance with the provisions of the international conventions, the ship’s related facilities must be equipped with various lamps to display various signals in order to indicate its location, status, and type when the ship is under night sailing, operation or low visibility. , In order to identify and avoid.



The light arc, visibility distance, chromaticity, enclosure protection, and installation position of navigation lights and signal lights have strict regulations.



Marine lighting lamps collectively referred to as lamps used for lighting on ships.



Cabin lights, ceiling lights, walkway lights, emergency lights, floodlights for deck work lighting, searchlights for the long-distance search of targets, explosion-proof lights for use in explosive atmospheres, portable lights for temporary workplaces, and Lighting lamps for living areas, etc.





Masthead light:



The signal lights placed above the mast of the ship or above the centerline of the fore and aft, display uninterrupted lights in a horizontal arc of 225 degrees, and the device should display the lights from the front of the ship to within 22.5 degrees behind each side.



Starboard light and Port light:



The red light on the port side and the green light on the starboard side, which are placed on the left and right sides of the highest deck of the ship, each display uninterrupted lights in a horizontal arc of 112.5 degrees. Displayed within 22.5 degrees behind the abbe. The sidelight shield facing the lamp surface shall be painted with matt black paint. The height of the shutter is at least equal to the height of the lamp. For barges with a length of 80 meters or more, red and green side lights shall be installed at the bow and stern.



Stern ight:



A white light located in the middle of the stern. Display uninterrupted lights in a horizontal arc of 135 degrees, and the device should make the lights display within 67.5 degrees of each side from directly behind the ship. The height of the masthead light should be as horizontal as possible, but not higher than the sidelight.



DS7-2M DS7-3M Weight 1.2Kg Power 60W 220V Marine Work Lights 2
